- High-concerned chemical: None
- Electronic: Yes
- Model Number: IPC28184EA-ADX5K-F40-I1-NB, IPC28184EA-ADX5K-F40-I1
- DIY Supplies: Electrical
- Origin: Mainland China
- Style: BULLET CAMERA, PTZ camera
- Certification: CE
- Place of Origin: China
- Warranty: 2 years
- Special Features: NIGHT VISION, Waterproof / Weatherproof, Built-in Siren, People Counti
- Sensor: CMOS
- Function: Two-way Audio, Alarm I/O, RESET, Built-in Mic, NIGHT VISION, Waterproo
- Video Compression Format: H.265
- Data Storage Options: DVR, Cloud, NVR, Micro SD card, SD Card
- Application: Indoor
- Customized support: Customized logo, OEM, ODM
- Lens: Other
- Support: P2P Support Audio
- Video Compression: Ultra 265, H.265, H.264, MJPEG
- Micro SD: 256GB
- Weight: 2.11kg
- Resolution: 8MP+4MP
- Audio I/O: 2/1
- Alarm I/O: 3/2
- Warm Light Distance: Up to 30m (98.43ft)
Hello, my dear friend. Thank you very much for visiting my store. I’m Kaia from China. You can find the products you need in my store. If you can’t find them or have any questions about the products you need, you can contact me via WhatsApp/WeChat +86 15111337116 or email x3319593926@sina.com. Welcome!
Some of the product prices in our store are incorrect and need to be renegotiated. Also, the inventory of some products is insufficient. Please confirm with the store before purchasing. We apologize for any inconvenience caused.
Contact information: WhatsApp: +86 15111337116 Email: x3319593926@sina.com
8MP+4MP Bi-Channel LightHunter Intelligent Bullet Network Camera
• One IP with two channels, combines the details and full view, making target area stand out without losing overall view
• 3840*2160@30fps in the main stream of detailed channel with ISP algorithm, provide high definition image
• Ultra 265, H.265, H.264, MJPEG
• Built-in dual Mic, efficiently realizes the noise control by noise reduction algorithm
• Two types of illumination light, offer three illumination modes and support sound-light warning
• Detailed channel supports electric control and tilt angle adjustment, easier for installation and debugging
• Switching among three Intelligent functions, suitable for various application scenes
• Mix-traffic detection, support human body, human face, motor vehicle and non-motor vehicle image capture and attribute collection, realize data visualization management, allow users to get target information for further data analysis
• Smart intrusion prevention, support false alarm filtering, realize accurate detection based on specific target
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Audio 2 in and 1 out, Alarm 3 in and 2 out
IPC28184EA-ADX5K-F40-I1 | |||||
Camera | |||||
Sensor | Channel 1 : 1/1.8″, 4.0 megapixel, progressive scan, CMOS Channel 2 : 1/1.8″, 8.0 megapixel, progressive scan, CMOS | ||||
Min. Illumination | Channel 1 : Colour:0.0005lux (F1.0, AGC ON) | ||||
Channel 2 : Colour:0.005lux (F1.6, AGC ON) | |||||
0 lux with IR | |||||
Day/Night | Channel 2 : IR-cut filter with auto switch (ICR) | ||||
Shutter | Auto/Manual, 1 ~ 1/100000s | ||||
Angle Adjustment | Channel 2 : Tilt: -10° to 10° (electric control , for installation and debugging) | ||||
WDR | 120dB | ||||
S/N | >56dB | ||||
Lens type | Channel 1 : 4mm Channel 2 : 10-50mm @F1.6, AF automatic focusing and motorized zoom lens | ||||
Optical Zoom | Channel 2 : 5X | ||||
Iris | Channel 1 : Fixed aperture Channel 2 : DC-iris | ||||
Field of View (H) | Channel 1 : 94.7° Channel 2 : 33.8°~8.4° | ||||
Field of View (V) | Channel 1 : 50.3° Channel 2 : 18.8°~4.6° | ||||
Field of View (D) | Channel 1 : 116.5° Channel 2 : 39.9°~10.0° | ||||
DORI | |||||
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
10 | 292.5 (959.6ft) | 117.0 (383.9ft) | 58.5 (191.9ft) | 29.3 (96.0ft) | |
50 | 1237.5 (4060.0ft) | 495.0 (1624.0ft) | 247.5 (812.0ft) | 123.8 (406.0ft) | |
4 | 79.1(259.6ft) | 31.7(103.9ft) | 15.8(51.9ft) | 7.9(26.0ft) | |
Illuminator | |||||
Warm Light Distance | Up to 30m (98.43ft) | ||||
IR Range | Up to 50m (164.0ft) IR range | ||||
IR Wavelength | 750nm | ||||
IR On/Off Control | Auto/Manual | ||||
Video | |||||
Video Compression | Ultra 265,H.265,H.264,MJPEG | ||||
Frame Rate | Channel 1 : Main Stream: 4MP(2688*1520),Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps Channel 2 : Main Stream: 8MP(3840*2160),Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps | ||||
U-code | Support | ||||
ROI | Up to 8 ROIs | ||||
Video stream | Triple streams | ||||
OSD | Up to 8 OSDs | ||||
Privacy Mask | Up to 8 areas(black/mosaic) | ||||
Image | |||||
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | ||||
Digital noise reduction | 2D/3D NR | ||||
Smart IR | Support | ||||
Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise | ||||
HLC | Support | ||||
BLC | Support | ||||
Defog | Digital Defog | ||||
Intelligent (Channel 2 Only) | |||||
Support collecting the attributes and images of pedestrian, vehicle and non-motor vehicle, offer information for further data analysis | |||||
Smart intrusion Prevention | Support false alarm filtering, Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection | ||||
Events | |||||
Basic Detection | Motion detection, Audio detection, Tampering alarm | ||||
General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication | ||||
Audio | |||||
Audio Compression | G.711U,G.711A | ||||
Audio Bitrate | 64 Kbps | ||||
Two way audio | Support | ||||
Suppression | Support | ||||
Sampling Rate | 8KHz | ||||
Storage | |||||
Edge Storage | Micro SD, up to 256 GB | ||||
Network Storage | ANR | ||||
Network | |||||
Protocols | IPv4,IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS | ||||
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API,SDK | ||||
User/Host | Up to 32 users. 3 user levels: administrator, operator and common user | ||||
Security | Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF | ||||
Client | EZStation EZView EZLive | ||||
Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above | ||||
Interface | |||||
Audio I/O | 2/1 | ||||
Alarm I/O | 3/2 | ||||
Serial Port | 1 RS485 | ||||
Built-in Mic | Support | ||||
Built-in Speaker | Support | ||||
Network | 1 x RJ45 10M/100M/1000M Base-TX Ethernet | ||||
Certifications | |||||
EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) | ||||
Safety | CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) | ||||
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) | ||||
Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) | ||||
General | |||||
Power | AC24V±25% Power consumption: Max 31w | ||||
Dimensions (Ø x H) | Φ326x147x121mm(Φ12.8”x5.8”x4.8”) | ||||
Weight | 2.11kg | ||||
Working Environment | -30°C ~60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | ||||
Storage Environment | -40°C ~70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) | ||||
Surge protection | Support | ||||
Reset button | Support | ||||
